Battery Testing Equipment Battery Mechanical Impact Tester
Brand: HBYIQI
Equipment Name: Battery Impact Tester
Standard basis: UL1642, UN38.3, IEC62100-2012, GB 31241-2022
Application: This battery tester simulates the impact influence to the battery pack or the cell that may occur during transportation.
Technical Parameter
| Model |
HBHSKT10 |
| Working platform |
200mm*250mm |
| Maximum load |
10 kg |
| Peak acceleration |
20-1500G |
| Pulse duration |
0.5-18ms |
| Maximum drop height |
1500mm |
| Equipment size |
L660*W700*H2380mm |
| Equipment weight |
525Kg |
| Measurement System |
| Input channels |
2 |
| Sampling frequency |
192KHz |
| Input |
Voltage, charge |
| Coupling mode |
AC, DC, ICP |
| Pulse duration |
50-0.1ms |
| Voltage range |
from -10V to +10V |
| Impact waveform |
Half-sine |
| Operating system |
Microsoft Windows7/10 |
| Communication interface |
USB2.0 |
|
Others
|
| Power supply |
AC220V±10％ 50Hz,1KVA |
| Compressed air |
0.5-0.8Mpa |
| Temperature |
RT~40℃ |
| Humidity |
25°C <85RH % |
Test Procedure
The test cells and battery packs are secured to the test device with rigid supports supporting all mounting surfaces of each test battery pack.
Each cell and battery pack is subjected to a half sine wave with a maximum acceleration of 150gn and a pulse duration of 6ms.
Each cell or battery pack is subjected to three shocks in the positive direction of the three perpendicular cell or battery pack mounting directions, followed by three shocks in the opposite direction, for a total of 18 shocks.
However, large cells and large battery packs are subjected to half sine waves with a maximum acceleration of 50gn and a pulse duration of 11ms. Each cell or battery pack is subjected to three shocks in the positive direction of the three perpendicular battery mounting directions, followed by three shocks in the opposite direction, for a total of 18 shocks.
Purchasing and consulting
We designate the experienced engineer and a foreign trade salesperson to answer your every question by multi-way of communication. We put a high value on your every requirement and will be honest and trustworthy, convenient and efficient mode to provide solutions and the most suitable equipment for you.
Service and maintenance
Our equipment maintenance experts are able to provide regular maintenance, repair and calibration of equipment systems to ensure that the system is always working at its best and strive to nip faults in the bud, thereby reducing maintenance costs and significantly extending the service life of measurement systems.
Upgrading and rebuilding
We will upgrade and rebuild the control system, software system and even the transmission system to make your equipment system under the best status, so that the technical advancement of the equipment has been greatly improved.
Installation and training
Before installation, please read the instruction manual; This manual introduces the detailed instruction of how to use the machine and all software functions. We also support training video to better solve your problems on time.
